Bollard lights

KOMPASS Bollard

Lighting Effects

Bollard with ultramodern design, created by the matching between two simple geometrical shapes that integrate it to every type of urban area. The comfort unidirectional diffuse optic with direct light, allows the bollards KOMPASS to light exclusively the direction where the light flux is directed, fully emphasizing the area or the subject, without glare. It is the ideal for public lighting of a pedestrian area, parking, and parks, perfect for private gardens or paths lighting. In order to meet the light projects requirements, it is available in different colour temperatures, powers and in three different heights.

  • Extruded aluminium body, basement and end caps in die-cast aluminium to ensure solidity and resistance
  • Silicone rubber seals for a high tightness
  • Temperate glass screen resistant to thermal shocks
KOMPASS Bollard kompass
kompass

Versions


LED Color


Color


Wiring


Code Optics Watt Lumen CCT CRI Wiring A B C
0882002A-840-16 one way 3W 50lm 4000K 80 ON/OFF 150mm 102mm 491mm
0882000A-840-16 one way 6W 100lm 4000K 80 ON/OFF 150mm 102mm 784mm
0882001A-840-16 one way 9W 150lm 4000K 80 ON/OFF 150mm 102mm 1077mm
